SBPF200 Series

Unit NO.	Dimensions(mm/in.)									Bolt Size mm/in.	Bearing NO.	Housing NO.	Weight(kg)
Unit NO.	d	a	e	m	s	t	f	B	n	Bolt Size mm/in.	Bearing NO.	Housing NO.	Weight(kg)
SBPF201	12	81	63.5	14	7.1	4	49	22	6	M6	SB201	PF204	0.27
SBPF201-8	1/2	3-3/16	2-1/2	9/16	9/32	0.157	1-59/64	0.8661	0.2362	1/4	SB201-8	PF204	0.27
SBPF202	15	3-3/16	2-1/2	9/16	9/32	0.157	1-59/64	0.8661	0.2362	1/4	SB202	PF204	0.27
SBPF202-9	9/16	3-3/16	2-1/2	9/16	9/32	0.157	1-59/64	0.8661	0.2362	1/4	SB202-9	PF204	0.27
SBPF202-10	5/8	3-3/16	2-1/2	9/16	9/32	0.157	1-59/64	0.8661	0.2362	1/4	SB202-10	PF204	0.27
SBPF203	17	3-3/16	2-1/2	9/16	9/32	0.157	1-59/64	0.8661	0.2362	1/4	SB203	PF203	0.27
SBPF203-11	11/16	3-3/16	2-1/2	9/16	9/32	0.157	1-59/64	0.8661	0.2362	1/4	SB203-11	PF203	0.27
SBPF204	20	90	71.5	16	9	4	56	25	7	M8	SB204	PF204	0.29
SBPF204-12	3/4	3-35/64	2-13/16	5/8	23/64	0.157	2-13/64	0.9843	0.2756	5/16	SB204-12	PF204	0.29
SBPF205	25	95	76	18	9	4	60	27	7.5	M8	SB205	PF205	0.33
SBPF205-13	13/16	3-3/4	2-63/64	23/32	23/64	0.157	2-23/64	1.063	0.2953	5/16	SB205-13	PF205	0.33
SBPF205-14	7/8	3-3/4	2-63/64	23/32	23/64	0.157	2-23/64	1.063	0.2953	5/16	SB205-14	PF205	0.33
SBPF205-15	15/16	3-3/4	2-63/64	23/32	23/64	0.157	2-23/64	1.063	0.2953	5/16	SB205-15	PF205	0.33
SBPF205-16	1	3-3/4	2-63/64	23/32	23/64	0.157	2-23/64	1.063	0.2953	5/16	SB205-16	PF205	0.33
SBPF206	30	113	90.5	18	11	5.2	71	30	8	M10	SB206	PF206	0.54
SBPF206-17	1-1/16	4-7/16	3-9/16	23/32	7/16	0.205	2-51/64	1.1811	0.315	3/8	SB206-17	PF206	0.54
SBPF206-18	1-1/8	4-7/16	3-9/16	23/32	7/16	0.205	2-51/64	1.1811	0.315	3/8	SB206-18	PF206	0.54
SBPF206-19	1-3/16	4-7/16	3-9/16	23/32	7/16	0.205	2-51/64	1.1811	0.315	3/8	SB206-19	PF206	0.54
SBPF206-20	1-1/4	4-7/16	3-9/16	23/32	7/16	0.205	2-51/64	1.1811	0.315	3/8	SB206-20	PF206	0.54
SBPF207	35	122	100	20	11	5.2	81	32	8.5	M10	SB207	PF207	0.68

Unit NO.	Dimensions(mm/in.)									Bolt Size mm/in.	Bearing NO.	Housing NO.	Weight(kg)
Unit NO.	d	a	e	m	s	t	f	B	n	Bolt Size mm/in.	Bearing NO.	Housing NO.	Weight(kg)
SBPF207-20	1-1/4	4-13/16	3-15/16	25/32	7/16	0.205	3-3/16	1.2598	0.3346	3/8	SB207-20	PF207	0.68
SBPF207-21	1-5/16	4-13/16	3-15/16	25/32	7/16	0.205	3-3/16	1.2598	0.3346	3/8	SB207-21	PF207	0.68
SBPF207-22	1-3/8	4-13/16	3-15/16	25/32	7/16	0.205	3-3/16	1.2598	0.3346	3/8	SB207-22	PF207	0.68
SBPF207-23	1-7/16	4-13/16	3-15/16	25/32	7/16	0.205	3-3/16	1.2598	0.3346	3/8	SB207-23	PF207	0.68
SBPF208	40	148	119	21	13.5	6.8	91	34	9	M12	SB208	PF208	1.14
SBPF208-24	1-1/2	5-13/16	4-11/16	13/16	17/32	0.268	3-37/64	1.3386	0.3543	1/2	SB208-24	PF208	1.14
SBPF208-25	1-9/16	5-13/16	4-11/16	13/16	17/32	0.268	3-37/64	1.3386	0.3543	1/2	SB208-25	PF208	1.14
SBPF209	45	150	120.5	23	13.5	6.8	98	41.2	10.2	M12	SB209	PF209	1.21
SBPF209-26	1-5/8	5-29/32	4-3/4	29/32	17/32	0.268	3-55/64	1.622	0.402	1/2	SB209-26	PF209	1.21
SBPF209-27	1-11/16	5-29/32	4-3/4	29/32	17/32	0.268	3-55/64	1.622	0.402	1/2	SB209-27	PF209	1.21
SBPF209-28	1-3/4	5-29/32	4-3/4	29/32	17/32	0.268	3-55/64	1.622	0.402	1/2	SB209-28	PF209	1.21
SBPF210	50	157	127	25	13.5	8	102	43.5	10.9	M12	SB210	PF210	1.49
SBPF210-29	1-13/16	6-3/16	5	63/64	17/32	0.315	4-1/64	1.7126	0.429	1/2	SB210-29	PF210	1.49
SBPF210-30	1-7/8	6-3/16	5	63/64	17/32	0.315	4-1/64	1.7126	0.429	1/2	SB210-30	PF210	1.49
SBPF210-31	1-15/16	6-3/16	5	63/64	17/32	0.315	4-1/64	1.7126	0.429	1/2	SB210-31	PF210	1.49
SBPF210-32	2	6-3/16	5	63/64	17/32	0.315	4-1/64	1.7126	0.429	1/2	SB210-32	PF210	1.49
SBPF211	55	168	138	26	13.5	8	113	45.3	11.8	M12	SB211	PF211	1.76
SBPF211-32	2	6-5/8	5-7/16	1-1/64	17/32	0.315	4-29/64	1.7835	0.465	1/2	SB211-32	PF211	1.76
SBPF211-33	2-1/16	6-5/8	5-7/16	1-1/64	17/32	0.315	4-29/64	1.7835	0.465	1/2	SB211-33	PF211	1.76
SBPF211-34	2-1/8	6-5/8	5-7/16	1-1/64	17/32	0.315	4-29/64	1.7835	0.465	1/2	SB211-34	PF211	1.76
