| Bearing NO. |
Dimensions(mm/in.) |
Dynamic load ratings(N) |
Static load ratings(N) |
Weight(kg) |
| d |
D |
B1 |
B |
C |
r |
S |
B5 |
d5 |
A |
ds |
| U000 |
10 |
26 |
17.5 |
11 |
8 |
0.5 |
4 |
8.5 |
17 |
3.5 |
M4X0.7 |
4606 |
1906 |
0.03 |
| SS-U000 |
10 |
1.0236 |
0.689 |
0.433 |
0.315 |
0.5 |
0.157 |
0.335 |
0.669 |
0.138 |
M4X0.7 |
4606 |
1906 |
0.03 |
| U001 |
12 |
28 |
17.5 |
11 |
8 |
0.5 |
4 |
8.5 |
19 |
3.5 |
M4X0.7 |
5096 |
2401 |
0.04 |
| SS-U001 |
12 |
1.1024 |
0.689 |
0.433 |
0.315 |
0.5 |
0.157 |
0.335 |
0.748 |
0.138 |
M4X0.7 |
5096 |
2401 |
0.04 |
| U002 |
15 |
32 |
18.5 |
12 |
9 |
0.5 |
4.5 |
8.5 |
22 |
3.5 |
M4X0.7 |
5586 |
2842 |
0.05 |
| SS-U002 |
15 |
1.2598 |
0.728 |
0.472 |
0.354 |
0.5 |
0.177 |
0.335 |
0.866 |
0.138 |
M4X0.7 |
5586 |
2842 |
0.05 |
| U003 |
17 |
35 |
20.5 |
13.5 |
10 |
0.5 |
5 |
9.5 |
25 |
3.5 |
M4X0.7 |
5978 |
3284 |
0.06 |
| SS-U003 |
17 |
1.3779 |
0.807 |
0.531 |
0.394 |
0.5 |
0.197 |
0.374 |
0.984 |
0.138 |
M4X0.7 |
5978 |
3284 |
0.06 |
| U004 |
20 |
42 |
24.5 |
16.5 |
12 |
1 |
6 |
11 |
30 |
5 |
M5X0.8 |
9359 |
5047 |
0.1 |
| SS-U004 |
20 |
1.6535 |
0.964 |
0.65 |
0.472 |
1 |
0.236 |
0.433 |
1.181 |
0.197 |
M5X0.8 |
9359 |
5047 |
0.1 |
| U005 |
25 |
47 |
25.5 |
17.5 |
12 |
1 |
6 |
12 |
36 |
5 |
M5X0.8 |
10094 |
5831 |
0.14 |
| SS-U005 |
25 |
1.8504 |
1.004 |
0.689 |
0.472 |
1 |
0.236 |
0.472 |
1.417 |
0.197 |
M5X0.8 |
10094 |
5831 |
0.14 |
| U006 |
30 |
55 |
26.5 |
18.5 |
13 |
1.5 |
6.5 |
12 |
42 |
5 |
M5X0.8 |
13230 |
8281 |
0.19 |
| SS-U006 |
30 |
2.1653 |
1.043 |
0.728 |
0.512 |
1.5 |
0.256 |
0.472 |
1.653 |
0.197 |
M5X0.8 |
13230 |
8281 |
0.19 |
| U007 |
35 |
62 |
29.5 |
20 |
14 |
1.5 |
7 |
13.5 |
48 |
5 |
M6X0.75 |
15920 |
10290 |
0.25 |
| SS-U007 |
35 |
2.44 |
1.161 |
0.787 |
0.551 |
1.5 |
0.276 |
0.531 |
1.889 |
0.197 |
M6X0.75 |
15920 |
10290 |
0.25 | |
|
|
