| Unit NO. |
Dimensions(mm/in.) |
Max.Torque |
Bearing NO. |
Housing NO. |
Weight(kg) |
| d |
h |
a |
e |
b |
s1 |
s2 |
g |
w |
B |
n |
Bolt D |
Nm |
| SS-UCPPL204 |
20 |
33.3 |
127 |
95 |
38 |
11 |
14 |
14.2 |
65.5 |
31 |
12.7 |
M10 |
18 |
SS-UC204 |
PPL204 |
0.29 |
| SS-UCPPL204 |
3/4 |
1-5/16 |
5 |
3-3/4 |
1-1/2 |
7/16 |
9/16 |
9/16 |
2-9/16 |
1.221 |
0.5 |
3/8 |
18 |
SS-UC204 |
PPL204 |
0.29 |
| SS-UCPPL205 |
25 |
36.5 |
140.5 |
105 |
38 |
11 |
14 |
14.5 |
71 |
34 |
14.3 |
M10 |
25 |
SS-UC205 |
PPL205 |
0.34 |
| SS-UCPPL205 |
13/16 ; 7/8 ; 15/16 ; 1 |
1-7/16 |
5-17/32 |
4-1/8 |
1-1/2 |
7/16 |
9/16 |
19/32 |
2-25/32 |
1.343 |
0.563 |
3/8 |
25 |
SS-UC205 |
PPL205 |
0.34 |
| SS-UCPPL206 |
30 |
42.9 |
163 |
119 |
46 |
14 |
18 |
17.8 |
84 |
38.1 |
15.9 |
M10 |
30 |
SS-UC206 |
PPL206 |
0.54 |
| SS-UCPPL206 |
1-1/16 ; 1-1/8 ; 1-3/16 ; 1-1/4 |
1-11/16 |
6-27/64 |
4-11/16 |
1-13/16 |
9/16 |
45/64 |
45/64 |
3-5/16 |
1.5 |
0.626 |
3/8 |
30 |
SS-UC206 |
PPL206 |
0.54 |
| SS-UCPPL207 |
35 |
47.6 |
168 |
127 |
48 |
14 |
18 |
18 |
94.5 |
42.9 |
17.5 |
M12 |
35 |
SS-UC207 |
PPL207 |
0.78 |
| SS-UCPPL207 |
1-1/4 ; 1-5/16 ; 1-3/8 ; 1-7/16 |
1-7/8 |
6-39/64 |
5 |
1-7/8 |
9/16 |
45/64 |
45/64 |
3-23/32 |
1.689 |
0.689 |
7/16 |
35 |
SS-UC207 |
PPL207 |
0.78 |
| SS-UCPPL208 |
40 |
49.2 |
184 |
137 |
54 |
14 |
18 |
19.5 |
99 |
49.2 |
19 |
M12 |
40 |
SS-UC208 |
PPL208 |
0.97 |
| SS-UCPPL208 |
1-1/2 ; 1-9/16 |
1-15/16 |
7-1/4 |
5-13/32 |
2-1/8 |
9/16 |
45/64 |
49/64 |
3-57/64 |
1.937 |
0.748 |
7/16 |
40 |
SS-UC208 |
PPL208 |
0.97 |
| SS-UCPPL209 |
45 |
54 |
192 |
146 |
54 |
17 |
20 |
23 |
106 |
49.2 |
19 |
M16 |
45 |
SS-UC209 |
PPL209 |
1.09 |
| SS-UCPPL209 |
1-5/8 ; 1-11/16 ; 1-3/4 |
2-1/8 |
7-9/16 |
5-3/4 |
2-1/8 |
43/64 |
25/32 |
29/32 |
4-11/64 |
1.937 |
0.748 |
5/8 |
45 |
SS-UC209 |
PPL209 |
1.09 |
| SS-UCPPL210 |
50 |
57.2 |
206 |
159 |
60 |
17 |
20 |
23 |
114 |
51.6 |
19 |
M16 |
50 |
SS-UC210 |
PPL210 |
1.2 |
| SS-UCPPL210 |
1-13/16 ; 1-7/8 ; 1-15/16 ; 2 |
2-1/4 |
8-1/8 |
6-1/4 |
2-3/8 |
43/64 |
25/32 |
29/32 |
4-31/64 |
2.032 |
0.748 |
5/8 |
50 |
SS-UC210 |
PPL210 |
1.2 |
| SS-UCPPL211 |
55 |
63.5 |
219 |
171 |
60 |
20 |
23 |
23 |
125 |
55.6 |
22.2 |
M16 |
55 |
SS-UC211 |
PPL211 |
1.38 |
| SS-UCPPL211 |
2 ; 2-1/16 ; 2-1/8 ; 2-3/16 |
2-1/2 |
8-5/8 |
6-47/64 |
2-3/8 |
25/32 |
29/32 |
29/32 |
4-59/64 |
2.189 |
0.874 |
5/8 |
55 |
SS-UC211 |
PPL211 |
1.38 |
| SS-UCPPL212 |
60 |
69.8 |
241 |
184 |
70 |
20 |
23 |
25 |
138 |
65.1 |
25.4 |
M16 |
60 |
SS-UC212 |
PPL212 |
1.52 |
| SS-UCPPL212 |
2-1/4 ; 2-5/16 ; 2-3/8 ; 2-7/16 |
2-3/4 |
9-1/2 |
7-1/4 |
2-3/4 |
25/32 |
29/32 |
63/64 |
5-7/16 |
2.563 |
1 |
5/8 |
60 |
SS-UC212 |
PPL212 |
1.52 | |
|
|
